Thickness: 0.1~16mm,or as customer’s requirements
Width: 10-2000mm or as customer’s requirements
Material: 201, 202, 301, 304, 304L, 309S, 310, 316, 316L, 321, 410S, 420, 430, 904L, etc
Surface: N0.1, N0.4, 2D, 2B, HL, BA, 6K, 8K, Mirror,etc
Standard: JIS, AISI, ASTM, GB, DIN, EN, etc
Certification: ISO, SGS, BV
Stock: 5000 Ton/Month
Quality control: Third Part Inspection is acceptable.
Delivery Time: Within 3 days for our stock size,15-20days for our production
Contact us: +86 13373795593
Alloy 304/304L resists atmospheric corrosion, as well as, moderately oxidizing and reducing environments. The alloy has excellent resistance to intergranular corrosion in the as-welded condition. Alloy 304/304L has excellent strength and toughness at cryogenic temperatures.
Alloy 304/304L is non-magnetic in the annealed condition, but can become slightly magnetic as a result of cold working or welding. It can be easily welded and processed by standard shop fabrication practices.
| Product | 304L Stainless Steel Coil |
| Surface Finish | BA, 2B, 4K, 6K, 8K, NO.4, HL, Embossed, Perforated, Pickling white, Polished outside, Polished inside and outside |
| Technique | Hot Rolled / Cold Rolled |
| Standard | AISI, ASTM, DIN, JIS, GB, JIS, SUS, EN, etc |
| Width | 500mm/1000mm/1219mm/1250mm/1500mm/1800mm/2000mm/2200mm/2500mm/3000mm/3500mm, or as required |
| Length | 500mm/1000mm/2000mm/2438mm/2500mm/3000mm/6000mm/8000mm—13000mm, or as required |
| Thickness | 0.4/0.5/0.6/0.7/0.8/0.9/1.0/1.2/1.5/2.0/2.5/3.0/4.0/5.0/6.0/8.0/10.0/12.0/14.0/16.0—250mm, or as required |
| Material | 201, 202 301, 302, 303, 303F, 303Cu, 304, 304L, 304H, 304F, 314 321, 316, 316L, 316Ti, 316F, 316LTi 309S, 310, 310S, 904L 409, 410, 416, 420, 430, 430F, 431, 436, 439, 441 317, 317L, 347H, 329, 630, 631, 17-4PH 2205, 2507, 2304, HASTELLOYC-276, C-22, C-2000, MONEL400, 254SMO, 253MA, Inconel1600, Inconel1625 Incoloy800, Incoloy800H, Incoloy825, Incoloy800HT GH3030, GH3039, GH2747 |
| Color | Standard RAL color: Red, Blue, White, Grey, Brick, etc. |
| Stock Dimension | Cold Rolled: 0.4-6.0mm*1000*2000mm/ 1220*2440mm/ 1250*2500mm/ 1500*3000mm, or as your request Hot Rolled: 3.0-16.0mm*1250*2500mm/ 1500*3000mm/ 1500*6000mm/ 1800*6000mm/ 2000*6000mm, or as your request Thick Sheet: 6.0mm-80mm*width*length, as your request Mirror: 0.4-1.5mm*1000*2000mm/ 1219*2438mm and other customize size workable Hairline: 0.4-1.5mm*1000*2000mm/ 1219*2438mm and other customize size workable Color Coating: 0.4-1.5mm*1000*2000mm/ 1219*2438mm and other customize size workable Sandblasting: 0.4-1.5mm*1000*2000mm/ 1219*2438mm and other customize size workable |
| Service | OEM, Customized processing service, Customized fabrication by drawings |
| Processing Type | Cutting, Bending, Stamping, Welding, CNC machining |
| Cutting Type | Laser cutting; Water-jet cutting; Flame cutting |
| Protection | 1. Inter paper available 2. PVC protecting film available |
| Application | Costruction Industry/ Kichten Products/ Fabrication Industry/ Home Decoration |
h5>
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 304L | Min. | ≤0.03 | ≤2.0 | ≤1.00 | ≤0.045 | ≤0.03 | 18.0～20.0 | / | 9.0～12.0 | |
| Max. | ||||||||||
| Grade | Euronorm | China GB | Japanese JIS |
| No. | |||
| 304L | 1.4307 | 00Cr19Ni10 | SUS304L |
| Stainless Steel Coil/Sheet/Plate Information | ||||||||||
| Technique | Surface Finish | Grade Series | Thickness(mm) | Width(mm) | Application | |||||
| Main Dimension | ||||||||||
| 20-850 | 1000 | 1219 | 1240 | 1250 | 1500 | |||||
| Hot Rolled | No.1 / 2E | 201/202/304 | 2.2-12.0 | √ | √ | √ | √ | √ | Petro-chemical industry,Tanks Construction material |
|
| Cold Rolled | 2B | 201/304 | 0.25-3.0 | √ | √ | √ | √ | √ | √ | |
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | |||||
| Hairline | 201/304 | 0.22-3.0 | √ | √ | √ | √ | √ | |||
| Mirror | ||||||||||
| SB | 410S/430 | 0.25-2.0 | √ | √ | √ | √ | √ | |||
| BA | 201/304 | 0.2--1.8 | √ | √ | √ | √ | ||||
| 410S/430 | 0.25-2.0 | √ | √ | √ | √ | |||||
| 2BA | √ | √ | √ | √ | ||||||
| Surface Finish | Definition | Application |
| 2B | Finished by heat treatment , picking or equipvalent cold rolling , followed by skin pass to obtain adequate luster surface. | With bright and smooth surface ,easy for further grinding to obtain brighter surface ,suitable for medical instruments ,milk containers ,tableware and so on. |
| BA | Bright heat treatment after cold rolling. | Structual members .etc.kitchen utensil ,cutlery ,eleltric applicances ,medical instruments ,building decorations ,etc. |
| NO.3/NO.4 | Polished with No.150-240 abrasives. | Milky food processing equipment , medicalinstruments ,building decorations. |
| HL | Finshed by polishing with abrasives of suitable grain size to obtain continuous streaks. | Building decorations ,such as elevators ,escalators ,door etc. |
| 6K/8K | A mirror-like reflective surface ,which is obtained by polishing with successively finer abrasives and buffing extensively with all gritlines are removed. | Buliding entrances,bulkding column casting ,elevator's wall doors ,counters,sculptur |
We have strict quality control before our products go out, And we have all kinds of board production equipment, you can meet your various needs.
1. Wide Specifications Range;
2. Pure steel chemical composition;
3. Outstanding mechanical properties;
4. Good performance after welding;
5. Good shape and high precision;
6. Excellent corrosion-resistant and long service life.
Stainless steel coils are widely used in below fields:
1. Used in industrial, chemical equipment;
2. Used in life stainless steel items;
3. Building materials, architectural decoration;
4. Storage tanks used for appliances and kitchen equipment.
We provide ordinary packaging for free, and can also customize packaging and logo according to buyers. Our common package are as below:
1. Coils covered with wooden plate for protection in transportation;
2. All coils will be loaded in strong wooden packages;
3. Every cartons loaded with good shoring and strengthening;
4. Take container loading pictures and seal the container;
5. Transportation speed is quick. And keep customer each step informed.
