Thickness: 0.1 mm-250 mm, or as customer’s request;
Width: 50 mm-3500 mm, or as customer’s request;
Material: Inconel 600/601/625, Hastelloy B, B-2, C-276, Monel 400, K500, W-21, Co,-50, GH605, GH3030 , etc;
Standard: AISI, ASTM, DIN, JIS, GB, JIS, SUS, EN, etc;
Certification: ISO SGS BV;
Surface: BA, 2B, 4K, 6K, 8K, NO.4, HL, Color Coating, Embossed, Perforated, etc;
Stock: 5000 Ton/Month;
PVC: 0.08 mm black/white PVC, Double blue PE, 0.1 mm laser PVC;
Contact us: +86 13373795593.
Nickel has good mechanical, physical and chemical properties, adding appropriate elements can improve its oxidation resistance, corrosion resistance, high temperature strength and improve some physical properties. Nickel alloys can be used as materials for electronic tubes, precision alloys (magnetic alloys, precision resistance alloys, electrothermal alloys, etc.), nickel-based superalloys, nickel-based corrosion-resistant alloys and shape memory alloys. Nickel alloys are widely used in energy development, chemical industry, electronics, navigation, aviation and aerospace and other sectors.
Nickel Alloy steel coil has higher strength and toughness than carbon steel, and its reinforcement effect with the increace of tissue imbalance and tend to be more obvious, and the strength of the nickel alloy steel coil annealing state than carbon steel has a lot of advantages, and in normalizing, than obviously increase the carbon steel and the strength of the nickel alloy steel coil after quenching and tempering, the steel reinforcement effect is the most significant. Some nickel alloy steel coils have excellent thermal hardness and other special properties, such as heat resistance, corrosion resistance, wear resistance and magnetic properties.
| Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy Coil | |
| Size |
Thickness: 0.1 mm-250 mm,or as customer's request; Width: 1000mm, 1219mm, 1250mm, 1500mm, or as customer's request; |
| Material Classification | |
| Monel Alloy | MONEL K-500, Monel400/2.4360, Monel 401. |
| Special Stainless Steel | 904L/UNS N08904/DIN1.4539, 254SMO/UNS S31254,253MA, 316Ti, 347H. |
| Duplex Stainless Steel | 1. 4462/2205/F60, 1.4028, 1.4016, 1.4006, S32101, S42000, SUS434, 1.4507, SUS416, SUS410, s31500, S31803, S32205/F51, 2507/S25073/F53. |
| Inconel Alloy | Inconel840 (S33400), Inconel 686 (2.4606-N06686), Inconel725 (NO7725), Inconel713C (2.4671), Inconel625 (2.4856), Inconel602ca (N06625), Inconel601 (2.4851), Inconel600 (2.4816), Inconel 690 (2.4642), Inconel617 (N06617), InconelX-750 (750), Inconel804, Inconel718 (2.4668). |
| Incoloy Alloy | Incoloy 800HT, Incoloy 890/1. 6569, Incoloy 810, Incoloy801, Incoloy 840/UNS S33400, Incoloy 20/UNS N08020, Incoloy 926/UNS N08926/1.4529, Incoloy 901/UNS N09901/2. 4662, Incoloy330/UNS N08330/1. 488, Incoloy945/ (UNS N09945) , incoloy A-286 /(UNS S66286/1.4980) , Incoloy 825/2.4858, Incoloy 925/UNS N09925, Incoloy 800H/800HT/800AT. |
| High Temperature Alloy | GH3308, GH3304, GH4090, GH738, GH3030, GH159 (GH6159) , GH3039, GH3044, GH3536, GH5188, GH1131, GH4141, GH2026, GH738, GH80A, GH4090, GH3600, GH2132, GH3625, GH3128, GH4145, GH4169, GH605 (GH5605) , GH93 (GH4093) , GH159 (GH6159) , Incoloy A-286, Inconel718, Incoloy825/2. 4858. |
| Hastelloy Alloy | Hastelloy AlloyB-2/Hastelloy B-2 Alloy, Hastelloy AlloyB3/Hastelloy B3 Alloy, Hastelloy C-2000 Alloy/Hastelloy AlloyC-2000, Hastelloy C-4/Hastelloy AlloyC-4/2. 4610, Hastelloy C-22/Hastelloy AlloyC22, Hastelloy AlloyC-276/Hastelloy C-276 Alloy. |
| Inconel | Element(% by mass) | ||||||||||||||
| Ni | Cr | Fe | Mo | Nb&Ta | Co | Mn | Cu | Al | Ti | Si | C | S | P | B | |
| 600 | ≥72.0 | 14.0-17.0 | 6.0-10.0 | ≤1.0 | ≤0.5 | ≤0.5 | ≤0.15 | ≤0.015 | |||||||
| 617 | 44.2-61.0 | 20.0-24.0 | ≤3.0 | 8.0-10.0 | 10.0-15.0 | ≤0.5 | ≤0.5 | 0.8-1.5 | ≤0.6 | ≤0.5 | 0.05-0.15 | ≤0.015 | ≤0.015 | ≤0.006 | |
| 625 | ≥58.0 | 20.0-23.0 | ≤5.0 | 8.0-10.0 | 3.15-4.15 | ≤1.0 | ≤0.5 | ≤0.4 | ≤0.4 | ≤0.5 | ≤0.015 | ≤0.015 | |||
| 690 | 59.5 | 30 | 9.2 | 0.35 | 0.01 | 0.02 | 0.35 | 0.019 | 0.003 | ||||||
| 718 | 50.0-55.0 | 17.0-21.0 | balance | 2.8-3.3 | 4.75-5.5 | ≤1.0 | ≤0.35 | ≤0.3 | 0.65-1.15 | ≤0.35 | ≤0.08 | ≤0.015 | ≤0.015 | ≤0.06 | |
| X-750 | 70 | 14.0-17.0 | 5.0-9.0 | 0.7-1.2 | 1 | 1 | 0.5 | 0.4-1.0 | 2.25-2.75 | 0.5 | 0.08 | 0.01 | |||
1. Pure nickel: high melting point (1455 degrees), good mechanical properties and cold and hot pressure processing performance, excellent corrosion resistance, is the best material for heat-resistant concentrated alkali solution corrosion, resistant to neutral and slightly acidic solutions and organic solvents , chemically stable in the atmosphere, fresh water and sea water, but not resistant to corrosion by oxidizing acids and high-temperature sulfur-containing gases. It is generally used as corrosion-resistant structure of machinery and chemical equipment, structural parts of precision instruments, electronic tubes and radio equipment parts, medical equipment and food industry tableware and utensils, etc.
2. Anode nickel: electrolytic nickel, pure in texture, and has depassivation effect. It is generally used as anode in electroplating nickel tanks. In electroplating, it dissolves evenly, produces less anode mud, and the coating is smooth and evenly distributed, and it is firmly combined with the substrate.
3. Nickel-manganese alloy: It has high room temperature and high temperature strength, good heat resistance and corrosion resistance, and excellent processing performance. In a sulfur-containing atmosphere at a higher temperature, the corrosion resistance is higher than that of pure nickel, and the thermal stability and resistivity are also higher than pure nickel. Generally used as spark plug electrodes of internal combustion engines, bulb filaments of resistance lamps, and grids of electronic tubes.
4. Nickel-copper alloy: There are two types, one has high corrosion resistance and is non-magnetic, and is generally used as anti-magnetic parts. The other type is also called Monel alloy. Its corrosion resistance is similar to that of nickel and copper, but its corrosion resistance to hydrofluoric acid is very good. The strength of the alloy is higher than that of pure nickel. It has good processing performance, high temperature resistance, and can It can be used stably in the atmosphere below 750 degrees, and maintains sufficient strength below 500 degrees. Generally used as high-strength, high-corrosion parts, high-voltage oil-filled cables, oil supply tanks, heating equipment and medical equipment parts.
1. We are Manufacture.
2. We are professional & enthusiasm to help & serve you.
3. We have rich export experience of exporting to may places, such as, India, Pakistan, Korea, Vietnam, Thailand, Bangladesh etc.
4. Our products are guarantee quality which can stand competition.
5. We consider the questions from the customer side.
6. We available free samples.
7. We welcome you come to visit our Manufacture.
1. Has good resistance to reduction, oxidation, and nitriding medium corrosion;
2. Good stress corrosion cracking resistance at room temperature and high temperature;
3. Good resistance to dry chlorine and hydrogen chloride gas corrosion;
4. Good mechanical properties at sub-zero, room temperature and high temperature;
5. Due to its good creep rupture strength for the control of carbon content and grain size, it is recommended to be used in a working environment above 700 ° C;
6. Excellent corrosion-resistant and long service life.
Alloy Steel Sheet are widely used in below fields:
1. Thermowell in an aggressive atmosphere;
2. Vinyl chloride monomer production: resistant to chlorine, hydrogen chloride, oxidation and carbonation corrosion;
3. Oxidation of uranium to hexafluoride: resistance to hydrogen fluoride corrosion;
4. Production and use of corrosive alkali metals, especially the environment where sulfides are used;
5. Preparation of titanium dioxide by chlorine;
6. Production of organic or inorganic chlorides and fluorides: resistant to chlorine and fluorine gas corrosion;
7. Nuclear reactor;
8. Curved neck flasks and components in heat treatment furnaces, especially in carbonizing and nitriding atmospheres.
